MONORAIL carriage (MR-W-35-D-G0-V3-CN)
Item #:
MR-W-35-D-G0-V3-CN
Availablity
In Stock
Available 62 Items
Typically ships within 3-5 days
| Material number | 580 107 448 | |
| Type (MONORAIL Carriage) | MR | |
| Carriage build form | D | |
| Buildsize | 35 | |
| Accuracy class | G0 | |
| Preload class | V3 | |
| Coating | CN |
| A | System height in mm | 55 |
| B | Carriage width in mm | 70 |
| B2 | Distance between locating faces | 18 |
| C1 | Position of center front lube hole | 14 |
| C3 | Position of lateral lube hole | 14 |
| C4 | Position of lateral lube hole | 25.5 |
| C7 | Position of lateral lube hole | 22.5 |
| J | Carriage height | 47 |
| L | Carriage length | 143 |
| L1 | Exterior fixing hole spacing | 72 |
| L6 | Steel body length | 103 |
| N | Lateral fixing hole spacing | 50 |
| O | Reference face height | 8 |
| C0 | Static load capacitiy (N) | 128,500 |
| C100 | Dynamic load capacity (N) | 71,500 |
| M0Q | Static cross moment capacity (Nm) | 2,762 |
| M0L | Static longitud. moment capacity (Nm | 2,214 |
| MQ | Dyn. cross moment capacity (Nm) | 1,537 |
| ML | Dyn. longitud. moment capacity (Nm) | 1,232 |
| Weight Rail (kg) | 2 |
